Semi-Automatic Vertical Action Circular Saw.
MT 315DXS Semi Automatic Saw
Heavy duty semi-automatic circular saw designed for fast cutting with automatic horizontal mitre positioning.
Standart Features
- Foot switch actuation
- Variable blade speed with inverter (20-80 rpm)
- High performance heavy duty gear box designed with fully hardened and grinded helical gears,
- Head descends on hardened roller type linear guides
- Hydro-pneumatic operation of saw head smoothes descent for optimum cut
- Easy, positive 0-45° right and 60° deg mitre left
- Coolant tank with box to collect chips and electric pump for blade lubrication and cooling
Optional Features
- Material support roller
- Saw Blade
Cutting Capacity
| CUTTING CAPASITY | |||
| Maximum Saw Blade Size Ø | 400 | ||
| Head Swivel | 90° | ±45° | +60° |
| Round (mm) | 120 | 120 | 90 |
| Square (mm) | 110×110 | 100×100 | 90×90 |
| Rectangle (mm) | 160×90 | 120×90 | 90×90 |
Technical Specifications
|
TECHNICAL SPECIFICATIONS |
||
|
Main Voltage (V) |
400 |
|
|
Control Voltage (V) |
24 |
|
|
Installed Power (kW) |
3,1 |
|
|
Nominal Current (A) |
7 |
|
|
Main Saw Motor (kW) |
3 |
|
|
Coolant Pump Motor (kW) |
0,06 |
|
|
Air Pressure (Consumption) |
6 kg/cm2 (240 ℓ /min) |
|
|
Blade Speed (RPM) |
20 – 80 By Inverter |
|
|
Head Swivel |
90°/±45°/+60° |
|
|
Saw Blade Size (mm) |
Diameter |
400 |
|
Bore |
40/50 |
|
|
Pin Holes |
4-15-80 |
|
|
Machine Dimensions (LxWxH) mm |
1.100X1.000X1.750 |
|
|
Net Weight (Kg) |
540 |
|
